Download the Wahoo App
|
The Wahoo app now provides device, sensor, and profile customization for the ELEMNT BOLT 3 as well as extended features/functionality with notifications, music control, and revised LiveTrack. The ELEMNT app will continue to support legacy ELEMNT computers as we work to migrate them into the Wahoo app, as well. |
Specifications
- Part Number: WFCC9
- Physical Dimensions: 3.26in x 1.85in x .78in // 83mm x 47mm x 24mm
- Weight: 3.4 oz // 84g
- Display
- Type: TFT
- Size: 2.3 in // 58.4 mm
- Resolution: 480 x 720px
- Colors: 16 million
- Memory
- Storage: 32 GB
- RAM: 2 GB
- Battery
- Type: USB rechargeable lithium-ion
- Life: Up to 20 hours
- Charger type: USB-C (24 in // 61 cm cable)
- Hardware
- Dual Band GPS
- Satellites: GPS, GLONASS, BEIDOU, Galileo, and QZSS
- Barometric altimeter
- Ambient light sensor
- Compass
- Gyroscope
- Accelerometer
- Dual Band GPS
- Connectivity
- Bluetooth LE 5.0
- ANT+, ANT+ FE-C
- Wi-Fi, dual band 2.4 and 5 Ghz
- Water Protection Rating: IPX7
- Operating Temperature: -4°F to 122°F / -20°C to 50°C
In the box
- ELEMNT BOLT 3 GPS Bike Computer
- Plastic Out-Front Mount (for 31.8 mm round bars)
- USB-C > C charging cable
- Important Product Info Guide
Core Features
Hardware
- Dual Band, multi-source GNSS (GPS) network connectivity
- provides GPS-based speed
- Barometric altimeter
- Dual-band (Bluetooth and ANT+) sensor connectivity
- Settings, sensors, and page configuration/customization with the Wahoo app for your smartphone
- Perfect View Zoom buttons
Navigation
- World maps available for free download via Wi-Fi
- Turn-by-turn navigation
-
On-device routing
- Get me started
- Creates the shortest viable route to the start point of a selected route.
- Back on track
- Auto-reroutes to the closest point of your loaded route in the direction of your loaded route
- Retrace ride
- Provides turn by turn directions to your ride's starting point based on your ride to this point
- Route to start
- Provides the shortest viable route back to your ride's starting point
-
App-based routing
- Take me to: Select and Save locations
- Select a location on in the Wahoo app* and save it to create an immediate route to that location, or for use later
- *Due to the lack of a touchscreen, BOLT 3 relies on your phone's keyboard for some more complex control interactions
- Select a location on in the Wahoo app* and save it to create an immediate route to that location, or for use later
- Create a route in the Wahoo app by sharing a location from Apple or Google Maps apps
- Create a route in the Wahoo app by importing a FIT, GPX, or TCX route file
- Create a route in the Wahoo app from a completed ride in your history
- Take me to: Select and Save locations
- Third party route syncing
Sensor Compatibility
- Broad hardware and partner app compatibility
-
KICKR Control
- ELEMNT BOLT 3 works seamlessly with the entire Wahoo ecosystem, and that includes giving you control over all KICKR smart bikes and smart trainers.
New Features
In addition to the features of the preceding ELEMNT computers, the BOLT 3 boasts the following NEW features:
-
2.3 inch // 58.4 mm, 16 million color TFT touch screen
- Offers a larger, clearer, updated interface with even more room for data, maps, and elevation profile details
-
Updated Ready-To-Ride dashboard
- Provides immediate access to workout profiles, routes, workouts, and paired/connected sensor data so you can select and confirm your ride plan, getting you riding faster.
- 32 GB of storage memory with 2 GB RAM
- Up to 20 hours battery life
Setup
